This issue reviews a thin and light gaming notebook - Thinkbook 16P. The machine configuration is as follows↓CPU: R7-5800H 8-core 16-thread graphics card: RTX3060 75W Direct-connected memory: Memory Technology 16G DDR4 3200MHz hard drive: Hynix PC711 512GB PCIe 3.0 screen: 16 inc

reviews a thin and light gaming notebook - Thinkbook 16P in this issue.

machine configuration is as follows ↓

CPU: R7-5800H 8 core 16 threads

Graphics card: RTX3060 75W Direct graphics connection

Memory: Memory Technology 6G DDR4 3200MHz

Hard drive: Hynix PC711 512GB PCIe 3.0

Screen: 16 inches 16:10 2.5K 100%sRGB 60Hz 400nits

Weight: Bare metal 2.05kg Adapter 0.85kg

Adapter power: 230W

Network card: AX200 Support WiFi6

Battery: 71Wh

Dimensions: length 356mm; width 252mm; height 20.5mm

Appearance:

A surface is made of metal, in silver and gray. In the upper left corner, the LOGO of Lenovo and Thinkbook;

screen:

HTML The 1 screen is a 16 -inch 16:10 2.5K 100%SRGB 60Hz screen, the screen brightness is 400 Nit;

measured screen Color gamut 95% sRGB, 68% NTSC.

color accuracy minimum value 0.38, maximum value 5.03, average value 1.92;

Keyboard:

full-size white backlit keyboard , with small numeric keyboard, full-height design of direction keys, backlight adjustable in 2 levels, with automatic brightness level;

0

Interface:

Left side: 3.5mm headset 2-in-1, SD card reader

Right side: Full-featured Type-C*2 (supports PD charging), security keyhole

Back side: USB-A*2, power interface

Performance test:

R20 single-core 546, multi-core 4757;

Tianxuan 3 Ryzen Edition 80W R7-6800H, R20 single-core 574 points, R20 multi-core 5200 points; the gap between R7-5800H and Tianxuan 3 Ryzen Edition multi-core is close to 8 %;

R23 single-core 1411, multi-core 11977;

3D Mark: 7419 points

hard disk test: read 3599MB/s, write 3074MB/s.

memory test: read 45105MB/s; write 34297MB/s; copy 39622MB/s; delay 79.6ns. The machine comes with 8G (onboard) + 8G (slot) memory, and a single card slot supports up to 16GB.

Fpu bakes the CPU for ten minutes alone, frequency 3.64GHz, maximum temperature 100.5℃, minimum temperature 60.9℃, average temperature 100℃; average power consumption 59W, minimum power consumption 9.9W, maximum power consumption 64.8W

donut bakes the graphics card alone for ten minutes , frequency 1590MHz, maximum temperature 78.2℃, minimum temperature 45.9℃, average temperature 74℃, average power consumption 74W, minimum power consumption 12W, maximum power consumption 75W;

Fpu+ donuts are double baked for ten minutes, frequency is about 3.1GHz, maximum temperature 100.5℃, minimum temperature 59.5℃, average temperature 91.7℃; average power consumption 36W, minimum power consumption 7.8W, maximum power consumption 64.8W;

graphics card frequency 520MHz, maximum temperature 81.4℃, minimum temperature 43.5℃, average temperature 77.8℃; The average power consumption is 69W, the minimum power consumption is 12.5W, and the maximum power consumption is 69.9W; when

is double baked, the surface temperature of the machine is as high as 58.1℃ and as low as 31.4℃; the highest temperature is mainly concentrated in the shaft area. Because it is a metal shell, the keyboard is under high load It is not recommended to touch the upper center position as it is very hot.

is about 20 centimeters away from the machine, the machine noise is about 44.5 decibels, and the noise is relatively small;

game test:

game test frame rate as shown in the figure↓

can be seen in the actual measurement, although it is 75W. 3060, but for the common ones currently on the market For large-scale games, at 2.5K resolution, you can play them smoothly with medium-high or full-high special effects at more than 60 frames.

Battery life test:

Test environment :

, Win11 power management is set to the best energy efficiency

, connect to WiFi, sound 40%, brightness 70%

, turn off independent display direct connection, turn on mixed mode

, set the operating mode to Energy saving mode

PCMARK10 The final result of modern office is 7 hours and 17 minutes;

uses the machine's built-in player to play a 4K game video. In the same measured environment, the power consumption is 15% in 1 hour. It is expected to last more than 6 hours after watching the video;

Advantages:

The appearance, texture and shell rigidity are very good

The screen quality is good

The noise is very small under high load

Disadvantages:

There are no USB-A ports on the left and right sides

The upper part of the keyboard is a bit hot under high load

screen refresh rate It is slightly lower than

. It is recommended that

be suitable for budget 6500. Friends who want to buy a high-quality thin and light gaming laptop or all-round laptop with good appearance, texture, shell material, configuration, noise control, , etc., TA is really a snake oil. It can also be considered a bucket.

The above is the entire content of this issue. Thank you for watching this and we will see you in the next issue!
