CORSAIR has launched another new product - the new H150i Elite all-in-one water cooling radiator is here.
new water cooling belongs to the iCUE RGB ELITE series. As we all know, this series has excellent appearance and performance, and is deeply loved by high-end players. This new product only uses RGB lighting design for the cold head and a matte design for the fan. If you are not pursuing RGB lighting, then this new H150i Elite all-in-one water cooling radiator is worth your consideration. This time,
will be displayed together with Corsair 5000T. I hope you will like it!
[Appearance]
The packaging of the new CORSAIR H150i Elite all-in-one water-cooled radiator continues the appearance design of this series. On the front is the appearance of this water-cooled . The fan does not have RGB lighting, only the water block supports it.
family portrait at a glance: water-cooled body, AF120 Elite matte fan*3, intel buckle, AMD/AM4 buckle, TR4 buckle*1, fan and cold head wire harness, user manual, and fixing screws. As for the latest 1700 buckle, this water cooling is also supported.
The newly designed integrated wiring harness is all integrated together, making installation and wiring much easier. This design is worth recommending. Only one 90° elbow USB Type-c cable can completely control the entire water cooling, awesome!
cold head water pump adopts an integrated design with good texture. It has built-in 16 independently addressable scattering RGB LED lamp beads, so the lighting effect is still very good. You will know it after it lights up.
has the word "Elite" printed on the side of the cold head, which translates to "elite", so it can be seen that this water cooling belongs to the elite series of Corsair. The light-transmitting plate on the front of the
cold head is magnetically designed to support player DYI and rotation, which is very convenient. If the player wants to make some personalized patterns, there is no problem. The problem is that Corsair does not come with a transparent shell this time, so if you DIY, you can only make it yourself.
pure copper base is currently the most mature solution. In addition, silicone grease has been sprayed before the water cooling is shipped from the factory. Needless to say, the advantages are that users can install it with confidence.
CORSAIR H150i Elite all-in-one water-cooling radiator The excellent heat dissipation effect is inseparable from the fins of the cold radiator. The thickness of the cold radiator is far higher than the height of the fins of the general cold radiator. It is equipped with an excellent fan, so it is necessary to have it. Such a powerful effect.
AF120 Elite new fan adds AirGuide technology, which can make the air flow more concentrated and improve the fluidity of the air volume, thus increasing the cooling effect. The speed adjustment range is 400-1850RPM, the air volume is 10.9-59.1CFM, the maximum wind pressure is 1.93mmH2O, and the maximum noise is 31.5dBA. Generally speaking, it is almost silent for normal use such as watching movies, writing copywriting, and drawing, and can only be used at full load. The sound will be louder.
looks like it after assembly. The all-black design looks cool.
[Other Hardware]
This time I used MSI MPG Z690 EDGE TI WIFI DDR4 Blade Titanium motherboard, and 12700k processor, paired with 32G memory, the configuration should be quite mainstream, hehe! The motherboard has a very classic black and white color scheme, the motherboard PCB is black, and the metal heat dissipation armor is silver. This design makes the visual impact very strong. The heat dissipation armor of the
motherboard is equipped with the Dragon Soul LOGO with RGB lights. When it is lit, the RGB lights will light up, which is very beautiful. In fact, if you are familiar with the and MSI series, you must be familiar with this design. The Blade Titanium motherboard has three PCI-E slots, the first of which is PCIe 5.0×16, directly connected to CPU, and is also equipped with metal protective armor. The second and third roots are PCIe 3.0 x4 and PCIe 3.0 x1. After all, the price and specifications are here.
CORSAIR RM1000x full-module power supply uses 105℃ all-Japanese industrial-grade high-performance capacitor , and supports the Modern Standby function, which will bring lower sleep standby power consumption and faster wake-up speed. It also has LLC topology circuit and DC to DC conversion design, which effectively reduces the noise of coil , is quieter and more efficient, and saves more power in sleep state.
passed the gold certification of 80 PLUS , with a conversion efficiency of 90%, a rated power of 1000W, and an output of 83.3A at 12V. It can be used for RTX 30 series high-performance independent graphics cards and AMD Ryzen CPUs, Intel Ten Second-generation Core components and other core components provide sufficient power support.
This time is using ZOTAC RTX3090 Apocalypse OC 24G graphics card. The Boost frequency has reached 1725MHz. The power supply material is 16+4 phase specifications, TDP350W. As for other parameters such as 24GB GDDR6X video memory, I believe everyone is familiar with it. You are familiar with it, so I won’t go into details here.
In addition, this ZOTAC RTX3090 Apocalypse OC 24G graphics card does a pretty good job in heat dissipation. It has a huge cooling module composed of 7 heat pipes and 3 fans on the front, and on the back, in addition to the metal backplate, two additional small fans are added, which effectively handles the heating problem of the video memory on the back of the RTX 3090.
[Installation Effect] The installation process of
will not be shown one by one here. Let’s look directly at the installation effect! I have to say that the white chassis is really beautiful. If the water cooling this time is white, it would be even more perfect, haha!
The effect after lighting up is really good. I finally know why Corsair has such a huge fan base. The product is excellent and the appearance is outstanding. It’s hard for you to like it or not. Can you not like it just by looking at it? Haha, I can’t yell anymore.
The two "little wings" of the ZOTAC RTX3090 Apocalypse OC 24G graphics card are really cute. Not only does it look good, but it also maximizes the heat dissipation effect, which is very good.
Let’s take a look at the overall effect. Oh, the solid color and RGB full-color appearance are very high.
[Driver]
After opening iCUE, you can see that the software has correctly identified the CORSAIR H150i Elite all-in-one water-cooled radiator. and CORSAIR iCUE 5000T RGB chassis. Through iCUE we can adjust the lighting mode of the chassis, the lighting effect of H150iELITE water cooling and the display effect of the display. It can be said that the playability is very high.
[My host]
Processor: Intel Core i9-12900K
Motherboard: MSI MPG Z690EDGFE TI WIFI DDR4
Hard drive: GUAWEI 1TB
Graphics card: ZOTAC RTX3090 Tianqi OC 24G
Monitor: MSI MPG ARTYMIS 323CQR
Radiator: CORSAIR H150i ELITE
Memory: ADATA XPG Longyao D50 DDR4-3600 16*2
Power supply: RM1000x gold medal full module
New CORSAIR H150i ELITE water-cooled daily standby, the processor temperature is only 27℃, and the core temperature fluctuates up and down at 24℃. The power consumption is 8W, and I am very satisfied with this temperature.
automatically boosts the frequency to 4.7Hz to single-bake the FPU, and turns off AVX. The processor power consumption is around 190W, the temperature is at 86°C, and the core temperature fluctuates around 78°C. I wonder what you think of this temperature?
[Monitor]
Finally, take a look at my gaming monitor. The PC version of God of War 4 has become very popular recently. As a fan of God of War, I will not miss it. My MSI Luna MPG ARTYMIS 323CQR gaming monitor is a 16:9 Proportional curved display , screen curvature 1000R.The screen size is 32 inches and the resolution is 2K level 2540×1440. The most eye-catching parameter is the refresh rate as high as 165Hz. It is a very good device for gamers. Therefore, it is very suitable to use it to play Kui Ye.
must be played with a controller. Really, there is no need to consider the keyboard, there is no experience at all. Paired with a game controller and MSI Luna MPG ARTYMIS 323CQR e-sports monitor, you can truly swim in the ocean of games.
Under ultra-high resolution special effects, Zotac RTX3090 Apocalypse OC 24G graphics card, average frame rate is 105 frames, the CPU temperature is 49°C, and the graphics card temperature is 71°C. The CPU temperature in actual use is still very low, which shows that the effect of the radiator is excellent. The occupancy rate of the graphics card is 100%, which can be said to be full power. However, the video memory usage is 28%. The large video memory is really amazing!
[Summary]
The performance of the new CORSAIR H150i Elite water-cooling radiator is still very good, continuing the fine tradition of iCUE RGB ELITE series water cooling. The pure copper base, AF120 Elite fan and blackened aluminum fin cooling radiator comprehensively improve the heat dissipation capacity. Paired with the CORSAIR iCUE 5000T RGB chassis, it can be said to have both good looks and new features.
ok That’s it for this sharing, I hope you all like it!
