On June 23, Yangtze River Storage released the commercial SSD PC300 series for the OEM market, which can be used in various scenarios such as notebooks, all-in-one computers, desktops, Internet of Things, embedded, and servers.
Yangtze Memory PC300 series uses its own Xtacking 2.0 crystal stack architecture, the third generation 3D NAND flash memory chip , with capacities of 256GB, 512GB, and 1TB.
Now, the Yangtze Storage PC300 1TB version has arrived in our evaluation room. Here is a picture tour for you.
Yangtze Memory PC300 offers two specifications: M.2 2242 and M.2 2280. The lengths are 42mm and 80mm respectively, and the weights are 4g and 8g respectively. We got the latter.
does not require any heat sink because its idle power consumption is only 50mW and its working power consumption is less than 5W.
The SSD supports interface protocols such as PCIe 4.0 x4 and NVMe 1.4. The
TB model has a maximum sequential read and write of 3.9GB/s and 2.8GB/s, and a random read and write of up to 380K IOPS and 450K IOPS.
has a mean time between failures of 2 million hours, and technically supports TCG-Pyrite, OPAL, LDPC error correction, full-path data protection, etc. The write life reaches 600TBW, which is equivalent to 0.33 full disk writes per day based on a five-year service life.
also supports HMB (Host Memory Buffer) and cooperates with the SLC caching mechanism to effectively ensure performance and reduce costs.
