In 2022, the competition for "all-round" sweeping and mopping robots will become increasingly fierce. In addition to automatic mop washing, automatic dust collection, automatic sterilization and other functions, many products will also promote "automatic water supply and drainage" as a key function, but they are all optional. Components are coming later. Among the many all-round new products, Roborock G10S series is not only launched early, but also takes the lead in promoting the application of intelligent water supply and drainage kits. At the same time, it also launches smart drying kits. Let’s take a look at the actual installation and usage experience.
Functional design and installation effect
The G10S series adopts a modular design. The automatic water supply and drainage kit can be easily installed. Just remove the original clean water tank and sewage tank and put them in directly. There is no sense of disharmony in the whole.
Other installation accessories include: power cord*1, two-part right-angle elbow*3, three-part right-angle elbow*2, three-part T-shaped elbow*1, three-part L-type plug connector*1, check valve *1, clean water three-way valve*1, tap water filter*1, two-part pipe*1, three-part pipe*1, wire bundle tube*1, wire bundle tube installer*1, two-part locking piece*10, three-point locking piece *14.
drying kit consists of two parts: the main unit and the base plate. The main unit is located on the side of the base. The new base plate has more air inlets and air outlets than before. First assemble the host and base plate together, and then connect it to the main body of the base, which is simple and quick.
Let’s look at the back of the fuselage. In the circuit part, the base power supply plug on the drying kit is connected to the base power interface, and there is also a power cord to supply power to the water supply and drainage kit; in the waterway part, the water inlet pipe interface, drainage pipe interface and overflow pipe interface are located on the back , the existence of the pipeline cannot be seen from the front after installation.
The waterway and circuit layout on the back of the fuselage
Actual installation renderings
Pre-installation reservation plan
Automatic water supply and drainage involves the connection and installation of the waterway, and it is necessary to consider the reservation of drainage and sockets during the pre-installation stage. There are two installation options, one is to embed water pipes in the wall, and the other is to reserve pipeline holes in the wall. If your home has been renovated, you can consider locations such as next to the washing machine on the balcony, in the kitchen, and in the bathroom drying area.
Installation service process
Before placing an order, you need to check whether it is in the installation area and whether it meets the installation conditions. After receiving the goods, make an appointment through the Roborock Technology Roborock WeChat public account. Roborock authorized engineers will confirm the time with the user and come to install it. The first installation is free.
Really frees your hands
The G10S series has a clean water tank capacity of 3L and a sewage tank capacity of 2.5L. In addition, the machine also comes with a 200mL water tank. During the mopping process, the mop will be continuously replenished with water, keeping the floor evenly wet and even when backwashing the mop. The onboard water tank will be refilled automatically.
Although the entire process does not require frequent manual addition of water, it still needs to be regularly added with clean water and dumped with sewage. A lack of water in the clean water tank or a full sewage tank will interrupt the cleaning task. After installing the water supply and drainage kit, adding clean water and discharging sewage can be completed automatically. There is no need to worry about adding clean water and pouring out sewage every now and then.
water supply and drainage kit also has a built-in cleaning fluid storage bin, which can hold 1L of cleaning fluid. It is automatically dispensed at a ratio of 1:200 each time, and there is no need to manually add cleaning fluid.
The cleaning liquid filling port on the top of the drying kit
has an independent cycle on and off key. You can start and stop drying with one click through the body buttons without a mobile phone. In addition, it also supports the mobile phone APP to start and stop and adjust the drying time; according to the location You can choose different drying times depending on the environment. 2-hour drying is suitable for general environments, 3-hour drying is suitable for humid environments, and 4-hour drying is suitable for high-humidity environments.
Before cleaning and drying the mop
After cleaning and drying the mop
The temperature of the air outlet of the drying kit is about 45°C, which can be used to quickly dry the mop with the 26 air outlets on the bottom plate. The hot air system has temperature protection to prevent overheating and avoid the impact of the drying process on the floor.The customized high-speed centrifugal fan has strong wind power but low noise, which is basically imperceptible during daily use. The addition of the
intelligent water supply and drying kit greatly reduces the frequency of manual intervention during daily use. It only needs to throw away the garbage once every 60 days and occasionally clean the base station filter. A truly smart product must have a very low sense of presence. Automatic water loading and unloading is a key part of freeing your hands, helping the Roborock G10S series to complete the ultimate evolution and achieve a true sense of freeing your hands.
